Silkland USB 4 Thunderbolt 4 Cable (Model S3601)

1. Okwu mmalite

The Silkland USB 4 Thunderbolt 4 Cable (Model S3601) is designed for high-performance connectivity, offering rapid data transfer, efficient power delivery, and high-resolution video output. This manual provides essential information for setting up, operating, maintaining, and troubleshooting your cable to ensure optimal performance.

2. Nhazi

This cable is designed for plug-and-play functionality, requiring no additional drivers for most devices. Simply connect the USB-C ends to compatible ports on your devices.

2.1 Connecting for Data Transfer, Charging, and Video Output

Connect one end of the Silkland USB 4 Thunderbolt 4 cable to your host device (e.g., laptop, tablet, smartphone) and the other end to your peripheral device (e.g., external SSD, monitor, docking station, power adapter). Ensure both devices support the desired functions (data, power, video) via their USB-C or Thunderbolt ports.

Image: Silkland USB 4 Thunderbolt 4 Cable connected to various devices, highlighting its capability for data, charging, and video.

Mara: For stable performance when connecting to a docking station, it is recommended to use cables below 5FT in length.

3. Ntuziaka ọrụ

3.1 High-Speed Data Transfer

The Silkland USB 4 Thunderbolt 4 cable supports data transfer speeds of up to 40Gbps, which is twice as fast as previous generation USB4 cables. This allows for rapid transfer of large files, such as music, movies, or entire seasons of TV shows, in mere seconds. Connect your compatible SSDs or other storage devices for optimal performance.

Image: Visual representation of 40Gbps data transfer speed, demonstrating how the cable facilitates quick file ndabere.

3.2 Power Delivery and Fast Charging

This cable supports up to 240W (48V/5A) fast charging, compatible with PD3.1, QC 4.0, FCP, and AFC fast charging technologies. It is backward compatible with 100W, 140W, and 180W chargers. The integrated E-Marker chip ensures safety, stability, and battery protection during charging. It is compatible with devices like iPhone 15/16/17, MacBook, iPad Pro, and GaN chargers.

Image: Illustrates the rapid charging capability of the Silkland 240W cable compared to standard 100W cables.

3.3 High-Resolution Video Output

Experience stunning visual quality with support for a single 8K@60Hz, 6K/5K@60Hz, or dual 4K@60Hz display. Connect your laptop or docking station to a compatible monitor to extend or mirror your display for presentations, video editing, or gaming.

Image: A high-resolution monitor showcasing 8K content, connected using the Silkland USB 4 cable.

Image: Multiple monitors set up in an MST Daisy Chain configuration, powered by the Silkland USB 4 cable for an efficient workspace.

4. Nlekọta

The Silkland USB 4 Thunderbolt 4 cable is constructed with top-notch materials for durability and longevity. The double nylon braided exterior provides flexibility and resistance to wear, while the aluminum alloy shell and sturdy tinplate connectors ensure stable connections.

Foto: Zuru ezu view of the cable's robust construction, emphasizing its durability and stable connection features.

Image: Illustration of the Smart E-Marker Chip, which intelligently matches current to extend device and battery lifespan.

4.1 Nlekọta n'ozuzu

• Avoid extreme bending or sharp angles to prevent internal damage.
• Debe njikọ ndị ahụ ka ọ dị ọcha na enweghị uzuzu ma ọ bụ irighiri ihe.
• Store the cable in a cool, dry place when not in use.

Mara: The shell dimensions of the connector are 12.2mm x 6.5mm. We recommend removing your phone case if it obstructs the connector for a secure fit.

5. Nchọpụta nsogbu

5.1 No Data Transfer / Slow Speeds

• Lelee ndakọrịta: Ensure both your host and peripheral devices support USB 4 or Thunderbolt 4/3 for optimal speeds. Older USB standards will operate at their maximum supported speed.
• Nyochaa njikọ: Disconnect and reconnect the cable firmly at both ends.
• Jiri ngwaọrụ ndị ọzọ nwalee: Try the cable with different compatible devices to isolate if the issue is with the cable or a specific device.

5.2 No Charging / Slow Charging

• Ihe nkwụnye ọkụ: Gbaa mbọ hụ na ihe nkwụnye ọkụ gị nwere ike ịnye mmiri zuru oketage (e.g., 240W, 140W, 100W) and supports PD3.1 or other fast charging protocols.
• Ndakọrịta ngwaọrụ: Confirm your device supports fast charging via USB-C/Thunderbolt.
• Ịdị n'ezi nke eriri USB: Lelee eriri ahụ maka mmebi ọ bụla a na-ahụ anya.

5.3 No Video Output / Incorrect Resolution

• DisplayPort Alt Mode: Ensure your host device's USB-C/Thunderbolt port supports DisplayPort Alternate Mode.
• Nyochaa ntinye: Họrọ isi mmalite ntinye ziri ezi na ihe nlele gị.
• Ntọala mkpebi: Adjust display settings on your computer to match the monitor's capabilities.
• Ogologo eriri USB: For high-resolution displays, shorter cables generally provide more stable signals.

6. Nkọwapụta

7. Akwụkwọ ikike & Nkwado

Silkland offers a 24-month customer care period for this product. If you encounter any issues or have questions regarding your Silkland USB 4 Thunderbolt 4 Cable, please do not hesitate to contact our dedicated support team. We are committed to resolving your concerns within 18 hours.

For support, please visit the official Silkland websaịtị ma ọ bụ kpọtụrụ onye na-ere ahịa ozugbo site na ikpo okwu ịzụrụ ihe.
