1. Ozi nchekwa dị mkpa
Please read this entire manual before assembling or operating the EVOLAND Foldable Exercise Bike. Keep this manual for future reference.
- Kpọtụrụ dọkịta gị tupu ịmalite mmemme mmega ahụ ọ bụla.
- Debe ụmụaka na anụ ụlọ n'ebe akụrụngwa nọ n'oge eji.
- Place the exercise bike on a flat, stable surface. Ensure adequate space around the bike.
- Inspect the equipment for worn or loose parts before each use. Do not use if damaged.
- Yiri uwe na akpụkpọ ụkwụ kwesịrị ekwesị maka mmega ahụ.
- The maximum user weight for this product is 120 n'arọ (264 lbs).
- Adjust the seat and handlebars to a comfortable and safe position before exercising.
- Kwụsị mgbatị ahụ ozugbo ma ọ bụrụ na ị na-ada mbà, isi ọwụwa, ma ọ bụ nwee mgbu.
2. Ihe ngwugwu
Jiri nlezianya kpochaa ihe niile ma hụ na ị nwetala ihe ndị a:
- 1 x EVOLAND Foldable Exercise Bike
- 1 x Akwụkwọ ntuziaka onye ọrụ
- Assembly Tools (usually included, refer to the separate assembly guide for specifics)
3. Ngwaahịa gafereview & Akụkụ ndị isi
The EVOLAND Foldable Exercise Bike (Model X1516) is designed for effective indoor cardio training. Its compact and foldable design makes it ideal for home use, offering a full-body workout with adjustable resistance levels and a clear LCD display.
Nyocha 3.1: N'eluview of the EVOLAND Foldable Exercise Bike.
3.1 Foldable Design
The bike features an 80% space-saving foldable structure, allowing for easy storage when not in use. This design minimizes the space required in your home, making it convenient to exercise anytime, anywhere.
Figure 3.2: The exercise bike in its folded position, demonstrating space-saving storage.
Ngosipụta L3.2 XNUMX
An integrated LCD screen provides real-time digital tracking of your workout metrics, including speed, time, distance, and calories burned. This helps you monitor your progress and improve exercise efficiency.
Figure 3.3: The LCD display showing various workout data.
3.3 8 Levels of Magnetic Resistance
The magnetic tension control system offers 8 levels of resistance, allowing you to customize your workout intensity. Adjust the resistance level at any time to suit your fitness goals, from beginner to advanced.
Figure 3.4: The resistance knob for adjusting workout intensity.
3.4 Sturdy and Durable Construction
Constructed with a robust steel frame, this exercise bike features an X-shaped design for stable and safe workouts. It is tested to support a maximum user weight of 120 kg.
Figure 3.5: Stable X-shaped design and anti-slip foot pads for secure use.
3.5 Adjustable Seat
The comfortable, padded seat is adjustable to accommodate various user heights, ensuring an ergonomic and effective workout position.
Figure 3.6: Adjustable seat for personalized comfort.
4. Ntọala na Mgbakọ
The EVOLAND Foldable Exercise Bike is designed for straightforward assembly. Most components are pre-assembled, and the necessary tools are included. For detailed, step-by-step instructions, please refer to the separate assembly guide provided in your package.
Ndụmọdụ Mgbakọ Ozuruọnụ:
- Gbaa mbọ hụ na akụkụ niile dị tupu ịmalite mgbakọ.
- Follow the numerical order of steps in the assembly guide.
- Do not overtighten bolts until instructed to do so.
- Seek assistance if needed, especially for lifting heavier components.
5. Ntuziaka ọrụ
5.1 Na-edozi ịdị elu oche
Ka ịgbanwee ogologo oche:
- Tụpụ ihe nrụzi dị n'elu ogidi oche ahụ.
- Raise or lower the seat to your desired height. Ensure your leg has a slight bend at the knee when the pedal is at its lowest point.
- Tighten the adjustment knob securely to lock the seat in place.
Video 5.1: Demonstration of adjusting the seat height and other features of the EVOLAND exercise bike.
5.2 Na-edozi Nguzogide
The exercise bike features 8 levels of magnetic resistance. To adjust the resistance:
- Locate the tension control knob on the main frame.
- Turn the knob clockwise to increase resistance (levels 1-8, 'High').
- Turn the knob counter-clockwise to decrease resistance (levels 8-1, 'Low').
Figure 5.2: Resistance levels guide for the tension control knob.
5.3 Iji Ngosipụta LCD
The LCD display tracks your workout data. Insert 2 AAA batteries (not included) into the monitor to activate it.
- Nyochaa: Na-akpaghị aka na-agagharị na ọrụ niile.
- OGE: Na-egosiputa oge mgbatị ahụ gị.
- SPD (Ọsọ): Na-egosi ọsọ ịgba ígwè gị ugbu a.
- DIST (Anya): Displays the distance covered during your workout.
- Calories (CAL): Na-eme atụmatụ kalori ndị ị gbara n'oge mmega ahụ.
Press the red button to cycle through display modes or hold it to reset values.
Figure 5.3: LCD display interface and tracked metrics.
6. Nlekọta
Nlekọta anya mgbe niile na-eme ka ogologo ndụ na ọrụ nchekwa nke igwe mgbatị ahụ gị dị.
- Nhicha: Jiri mgbasa ozi hichapụ igwe kwụ otu ebeamp ákwà mgbe ọ bụla iji wepụ ọsụsọ na ájá. Zenarị ndị na-ehicha ihe abrasive.
- Nyocha: Na-elele boltị niile, mkpụrụ, na akụkụ ndị na-agagharị agagharị mgbe niile iji mara ma hà siri ike. Mee ka ihe njide ọ bụla na-adịghị ike sie ike.
- Nchekwa: When not in use, fold the bike and store it in a dry, cool place away from direct sunlight and moisture.
7. Nchọpụta nsogbu
If you encounter any issues with your EVOLAND exercise bike, refer to the following common problems and solutions:
| Nsogbu | Ihe nwere ike ime | Ngwọta |
|---|---|---|
| Mkpọtụ ma ọ bụ mkpọtụ n'oge ọrụ | Loose bolts or components; internal friction. | Check and tighten all visible bolts and nuts. Ensure the bike is on a level surface. If noise persists, contact customer support. |
| Ngosipụta LCD anaghị arụ ọrụ | Batteries are dead or incorrectly installed; loose connection. | Replace batteries (2 AAA). Ensure batteries are inserted with correct polarity. Check the connection cable to the monitor. |
| Nguzogide anaghị agbanwe | Tension cable issue; resistance mechanism fault. | Ensure the tension control knob is properly engaged. Check if the resistance cable is securely connected. Contact customer support if the issue persists. |
If you experience any issues not listed here, or if the suggested solutions do not resolve the problem, please contact EVOLAND customer support.
8. Nkọwapụta
- Nọmba nlereanya: X1516
- Ihe: Alloy Steel
- Agba: Oji/Ọcha
- Usoro nguzogide: Magnetik
- Ọnụọgụ nke ọkwa mgbochi: 8
- Sistemụ mbanye: Belt
- Isi mmalite ike: Battery Powered (for LCD display)
- Batrị achọrọ: 2 AAA (anaghị etinye ya)
- Akụkụ ngwaahịa (L x W x H): 87.5 x 39 x 21.5 cm (34.4 x 15.4 x 8.5 inch)
- Ibu ihe: 14.3 Kilogram (31.5 lbs)
- Nkwanye ịdị arọ kachasị: 120 Kilogram (264 lbs)
- Njirimara Pụrụ Iche: Enwere ike mpịaji
- Eji akwadoro: Ime ụlọ
- Ogologo afọ: Okenye
9. Akwụkwọ ikike na nkwado
EVOLAND products are manufactured to high-quality standards. For warranty information, product support, or to report any issues, please contact EVOLAND customer service through the retailer where you purchased the product or visit the official EVOLAND websaịtị.
Please have your model number (X1516) and purchase date ready when contacting support.
