EUHOMY IM004-CSI Automatic Ice Maker User Manual

1. Ntuziaka nchekwa dị mkpa

Biko gụọ ntuziaka niile nke ọma tupu i jiri ngwa ahụ. Debe akwụkwọ ntuziaka a maka ntụnye aka n'ọdịnihu.

• Gbaa mbọ hụ na ọkọnọ ike dabara na voltage akọwapụtara na akara ọkwa.
• Ejila ngwa, eriri ọkụ, ma ọ bụ nkwụnye na mmiri ma ọ bụ mmiri mmiri ndị ọzọ.
• Unplug from the outlet when not in use, before cleaning, or during maintenance.
• Ejila ngwa ọ bụla nwere eriri ma ọ bụ plọg mebiri emebi rụọ ọrụ, ma ọ bụ mgbe ngwa ahụ dara ma ọ bụ mebie n'ụzọ ọ bụla.
• Ngwa a bụ maka naanị ụlọ. Ejila n'èzí.
• Debe ngwa ahụ pụọ na ebe okpomọkụ na ìhè anyanwụ.
• Ensure proper ventilation around the unit. Maintain at least 15cm clearance on all sides.
• Jiri naanị mmiri a na-eri anụ na tank mmiri.
• Echekwala ihe mgbawa dị ka ite aerosol nwere ihe na-ere ọkụ n'ime ngwa a.

2. Ngwaahịa gafereview

The EUHOMY IM004-CSI is an automatic ice maker designed for convenient ice production at home or for small business use. It features high-speed ice making, adjustable ice thickness, and an automatic cleaning function.

Image: The EUHOMY IM004-CSI ice maker filled with clear ice cubes, highlighting its capacity and rapid ice production capabilities.

Ọdịnaya ngwugwu:

• EUHOMY IM004-CSI Ice Maker
• Ihe nkata ice
• Akara Ice
• Akwụkwọ ntuziaka onye ọrụ

3. Nhazi

3.1 Mwepu na ntinye

1. Wepu ihe nkwakọ ngwaahịa niile wee lelee mmebi ọ bụla.
2. Debe onye na-eme ice n'elu kwụsiri ike, dị larịị, pụọ na ìhè anyanwụ kpọmkwem na ebe okpomọkụ.
3. Ensure there is at least 15cm of space around the unit for proper ventilation.
4. Hapụ ngwaọrụ ahụ ka ọ guzoro ọtọ ruo opekata mpe awa abụọ tupu etinye ya na ya, ọkachasị ma ọ bụrụ na ebufere ya n'akụkụ kwụ ọtọ. Nke a na-eme ka refriji ahụ daa.

3.2 Nhicha mbụ

Before first use, clean the ice maker thoroughly.

1. Mepee mkpuchi ma wepụ nkata ice.
2. Clean the interior with a soft cloth and warm water with a mild detergent. Rinse thoroughly.
3. Drain any remaining water by removing the drain plug at the bottom.
4. Jiri mgbasa ozi hichaa mpụtaamp akwa .

3.3 Water Filling Methods

The ice maker offers two convenient ways to add water to its 3.2L tank:

Image: Illustration showing two ways to fill the water tank: directly pouring water into the tank or using an inverted water bottle (up to 5cm diameter opening).

• Method 1: Direct Fill
  Open the lid and directly pour potable water into the water tank until it reaches the MAX fill line.
• Method 2: Water Bottle Connection
  Place an inverted water bottle (with a mouth diameter of 5cm or less) onto the designated water inlet. The ice maker will automatically draw water as needed.

4. Ntuziaka ọrụ

4.1 Ogwe njikwa gafereview

Foto: nkọwa zuru ezu view of the ice maker's control panel, showing buttons for power, timer/clean, ice full indicator, water shortage indicator, and ice size adjustment.

• Bọtịnụ ngbanwu/ Gbanyụọ: Na-agbanye unit ahụ ma ọ bụ gbanyụọ.
• Bọtịnụ TIMER/Ọ dị ọcha: Press once to set the timer. Press and hold for 5 seconds to activate the automatic cleaning function.
• Ihe ngosi zuru oke nke ice: Lights up when the ice basket is full.
• Mmiri mmiritage egosi: Lights up when the water tank is low.
• +/- bọtịnụ: Hazie ọkpụrụkpụ ice ma ọ bụ ntọala ihe nhazi oge.

4.2 Usoro Ime Ice

1. Ensure the water tank is filled with potable water.
2. Tinye onye na-eme ice n'ime oghere eletrik gbadoro ụkwụ.
3. Pịa Gbanye/ Gbanyụọ bọtịnụ iji malite okirikiri ime ice.
4. The unit will produce 24 clear ice cubes per cycle, taking approximately 12-18 minutes depending on ambient temperature and selected ice thickness.
5. When the ice basket is full, the ice full indicator will light up, and the unit will pause ice production. Remove ice to resume.
6. If the water level is low, the water shortage indicator will light up. Add more water to continue ice production.

4.3 na-edozi oke ice

You can adjust the thickness of the ice cubes to suit your preference.

Image: Visual representation of ice thickness adjustment, showing different ice cube sizes corresponding to various production times (0-10 min, 10-15 min, 15-20 min).

Jiri ihe +/- buttons on the control panel to select your desired ice thickness. A longer production time results in thicker ice.

4.4 Ọrụ ngụ oge

The ice maker features a timer function, allowing you to schedule ice production up to 8 hours in advance.

Image: The ice maker with a visual indicating a 24-hour timer function, suggesting convenience for scheduled ice production.

1. Pịa Oge/Ọcha bọtịnụ otu ugboro.
2. Jiri ihe +/- bọtịnụ iji tọọ oge igbu oge achọrọ (n'ime awa).
3. The unit will start ice production after the set time has elapsed.

5. Nlekọta

5.1 Ọrụ Nhicha Akpaka

The ice maker is equipped with an automatic cleaning function to simplify maintenance.

Image: An animated diagram illustrating the internal water circulation during the automatic cleaning cycle, showing water being thoroughly circulated and drained.

1. Gbaa mbọ hụ na tank mmiri jupụtara na mmiri dị ọcha.
2. Pịa ma jide Oge/Ọcha bọtịnụ maka 5 sekọnd.
3. The cleaning cycle will begin and last for approximately 20 minutes.
4. After the cycle, drain the water from the unit.

5.2 Mmiri Ịwụpụ Mmiri

Ka igbapu mmiri na unit:

1. Kwụpụ ihe na-eme ice ahụ na ebe a na-ere ọkụ eletrik.
2. Chọta plọg drain n'ala nke ngwaọrụ ahụ.
3. Place a container under the drain plug and remove the plug to allow water to flow out.
4. Ozugbo ewepụchara ya, dochie plọg ahụ nke ọma.

5.3 Nhicha mgbe niile

For optimal performance and hygiene, perform regular cleaning:

• Clean the ice basket and ice scoop with warm, soapy water.
• Jiri nwayọ hichaa mpụta nke otu ahụ, damp akwa .
• Periodically clean the water tank and ice-making components using a solution of water and vinegar (10:1 ratio) to prevent mineral buildup. Run a cleaning cycle with this solution, then rinse by running two cycles with fresh water.

6. Nchọpụta nsogbu

Rụtụ aka na tebụl dị n'okpuru maka okwu nkịtị na azịza ha.

7. Nkọwapụta

8. Akwụkwọ ikike na nkwado ndị ahịa

8.1 One-Year Quality Guarantee

Image: A badge indicating a "ONE YEAR GUARANTEE" for the product.

EUHOMY provides a one-year quality guarantee for this product. All products undergo strict quality inspection before shipment to ensure customer satisfaction.

8.2 Nkwado ndị ahịa

Image: Customer support representatives wearing headsets, ready to assist.

Should you encounter any issues or have questions regarding your EUHOMY ice maker, please do not hesitate to contact our customer support team. We are committed to providing prompt and courteous service.

For inquiries after purchase, please follow these steps:

1. Go to your Amazon "Order History."
2. Select "Problem with order."
3. Choose "View profile."
4. Click "Ask a question."

Alternatively, you may contact the dedicated customer service channel provided in the Japanese instruction manual included with your product.
