1. Okwu mmalite
This manual provides detailed instructions for the setup, operation, and maintenance of your Zenwire E520h projector. Please read this manual thoroughly before using the device to ensure proper functionality and to maximize your viewahụmahụ.
The Zenwire E520h is a Full HD 1080p projector with 4K support, featuring Android 9.0, dual-band WiFi (2.4/5 GHz), and Bluetooth 5.0 for versatile home theater entertainment.
2. Ihe ngwugwu
Chọpụta na ihe niile dị na ngwugwu:
- Zenwire E520h Projector
- Njikwa anya (batrị etinyeghị)
- Igwe ọkụ ọkụ
- HDMI USB
- AV Cable (stereo)
- Akwụkwọ ntuziaka onye ọrụ
The image above displays the Zenwire E520h projector along with its standard accessories: a remote control, power cable, HDMI cable, and AV cable. These components are essential for setting up and operating your projector.
3. Ngwaahịa gafereview
Familiarize yourself with the various parts and connections of your Zenwire E520h projector.
Foto a na-enye nkọwa zuru oke view of the projector from different angles, highlighting the lens, control panel, ventilation grilles, and various input/output ports located on the sides and rear of the device.
The Zenwire E520h projector supports a wide range of multimedia devices, including streaming sticks (Roku, Fire TV, Chromecast), external audio systems, USB storage, gaming consoles (Xbox, PlayStation), mobile devices (phones, tablets), DVD players, and computers (laptops, desktops) via its various input ports.
4. Nhazi
4.1 Ntinye
Position the projector on a stable, flat surface. Ensure adequate ventilation around the device. The optimal projection distance ranges from 1.2 to 6 meters, allowing for screen sizes from 36 to 200 inches.
This image demonstrates how varying the distance between the projector and the screen affects the projected image size, showing examples for 45, 120, and 200-inch displays.
4.2 Njikọ ike
Connect the power cable to the projector's power input and then plug it into a suitable electrical outlet.
4.3 Ike mbido
Press the power button on the projector or the remote control to turn on the device. The projector will boot into the Android 9.0 operating system.
5. Ntuziaka ọrụ
5.1 Ndozi Isi Ihe na Ndozi Isi Ihe
Adjust the focus ring around the lens until the image is clear. Use the 4D keystone correction feature to adjust the image shape if the projector is not perfectly perpendicular to the screen. This can be done via the remote control or on-screen settings.
This image illustrates the process of adjusting the focus ring on the projector lens and demonstrates the effect of keystone correction on the projected image, ensuring a rectangular display even when the projector is angled.
5.2 Android 9.0 Smart System
The projector runs on Android 9.0, allowing direct access to streaming applications like YouTube, Netflix, HBO, and Spotify. Navigate the interface using the remote control.
The image above shows the projector's smart interface, featuring a grid of popular streaming applications, demonstrating the integrated Android 9.0 system's capability to run apps directly.
5.3 Wireless Connectivity (WiFi & Bluetooth)
WiFi: Connect to your home network using the integrated 2.4/5 GHz WiFi. This enables Miracast and Airplay for wireless screen mirroring from iOS, Android, and Windows devices.
This image illustrates the projector's wireless connectivity, showing it mirroring content from a smartphone and tablet, and highlighting its compatibility with iOS, Android, and Windows 10 devices for screen sharing.
Bluetooth Bluetooth: Pair with external Bluetooth speakers, soundbars, or headphones for enhanced audio. Go to the settings menu to manage Bluetooth devices.
5.4 Wired Connectivity
Ihe ngosi ahụ nwere ọtụtụ ọdụ ụgbọ mmiri maka njikọ waya:
- HDMI (x2): Connect laptops, gaming consoles, Blu-ray players, or streaming devices.
- USB: Kpọọ mgbasa ozi ozugbo site na draịvụ USB.
- Nke: Jikọọ ngwaọrụ ndị ochie site na iji eriri AV dị na ya.
- Mini-Jack: Maka mmepụta ọdịyo mpụga.
- Micro-SD/TF Card Reader: For playing media from memory cards.
6. Nlekọta
6.1 Ihicha oghere
Gently wipe the projector lens with a soft, lint-free cloth specifically designed for optical surfaces. Do not use abrasive cleaners or excessive force.
This diagram illustrates the multi-element lens system of the projector, highlighting the precision optics that require careful handling during cleaning to maintain image quality.
6.2 Mgba ikuku
Ensure that the projector's ventilation openings are not blocked to prevent overheating. Regularly check for dust accumulation and clean if necessary using compressed air.
6.3 Nchekwa
When not in use for extended periods, store the projector in a cool, dry place, away from direct sunlight and excessive dust. Use the original packaging or a protective case.
7. Nchọpụta nsogbu
| Nsogbu | Ihe nwere ike ime | Ngwọta |
|---|---|---|
| Ọnweghị onyonyo egosiri | Power cable disconnected, incorrect input source, lens cap on. | Check power connection, select correct input source (HDMI, USB, etc.), remove lens cap. |
| Onyonyo edoghi anya | Focus not adjusted, keystone incorrect. | Adjust the focus ring, use keystone correction. |
| Enweghị ụda | Volume too low, incorrect audio output selected, external device muted. | Increase projector volume, check audio settings, ensure external device is not muted. |
| Nsogbu njikọ WiFi | Incorrect password, router too far, interference. | Verify WiFi password, move projector closer to router, check for other wireless devices. |
8. Nkọwapụta
| Njirimara | Nkọwa |
|---|---|
| Nlereanya | Zenwire E520h |
| Mkpebi obodo | 1920 x 1080p (Full HD) |
| Mkpebi akwadoro | Ruo 4K |
| Icha ọkụ | 9000 lumens (300 ANSI) |
| Ọnụọgụ ọdịiche | 2000:1 |
| Sistemụ nrụọrụ | Android 9.0 |
| WiFi | 2.4/5 GHz (Miracast, Airplay support) |
| Bluetooth | 5.0 |
| Njikọta | 2x HDMI, USB, AV, Mini-Jack, Micro-SD/TF |
| Nha amụma | 36-200 sentimita asatọ |
| Ogologo amụma | Mita 1.2 - 6 |
| Keystone Ndozi | 4D (manual and auto) |
| Voltage | 230 Volt |
| Akụkụ (Ngwugwu) | 23 x 18.5 x 10.5 cm |
| Ibu (Ngwugwu) | 1.2 n'arọ |
9. Akwụkwọ ikike na nkwado
For warranty information and technical support, please refer to the contact details provided with your purchase documentation or visit the official Zenwire websaịtị. Debe ihe akaebe nke ịzụrụ maka akwụkwọ ikike.
